Dimensions |
|
|---|---|
| Usable basket Ø | 1520 mm |
| Usable height | 550 mm |
| Loading height | 910 mm |
| Total height (machine) | 1400 mm |
| Total width (machine) | 2200 mm |
| Total depth (machine) | 2000 mm |
| Total weight (machine) | 500 kg |
Load |
|
| Permissible basket load | 500 kg |
Cleaning |
|
| Liquid volume | 450 l |
| Pump delivery rate | 450 l/min |
| Injection pressure | 4.5 bar |
Supply |
|
| Connected loads | 230/400 V / 50 Hz |
| Pump motor VA | 5.5 kW |
| Heat output | 3 x 5 kW |
| Rotary basket drive | 0.09 kW |
| 1-stage steam extraction | 0.45 kW |
