Dimensions |
|
|---|---|
| Usable basket Ø | 690 mm |
| Usable height | 350 mm |
| Loading height | 925 mm |
| Total height (machine) | 1270 mm |
| Total width (machine) | 1100 mm |
| Total depth (machine) | 1200 mm |
| Total weight (machine) | 200 kg |
Load |
|
| Permissible basket load (surface weight/load increase possible) | 200 kg |
Cleaning |
|
| Liquid volume | 105 l |
| Pump delivery rate | 150 l/min |
| Injection pressure | 3 bar |
Supply |
|
| Connected loads | 230/400 V / 50 Hz |
| Pump motor VA | 1.5 kW |
| Heat output | 6 kW |
| Rotary basket drive | 0.09 kW |
| 1-stage steam extraction | 0.11 kW |
