Dimensions |
|
|---|---|
| Usable basket Ø | 790 mm |
| Usable height | 500 mm |
| Loading height | 930 mm |
| Total height (machine) | 1390 mm |
| Total width (machine) | 1350 mm |
| Total depth (machine) | 1650 mm |
| Total weight (machine) | 290 kg |
Load |
|
| Permissible basket load (surface weight/load increase possible) | 500 kg |
Cleaning |
|
| Liquid volume | 150 l |
| Pump delivery rate | 200 l/min |
| Injection pressure | 3 bar |
Supply |
|
| Connected loads | 230/400 V / 50 Hz |
| Pump motor VA | 1.5 kW |
| Heat output | 6 kW |
| Rotary basket drive | 0.09 kW |
| 1-stage steam extraction | 0.11 kW |
